Description
IBUKI A150 Air Horn, Vessel Length 75-200m
| HORN-IBU-A3C2P- | AIR HORN c/w: MAGNET Valve, 110VAC | A150ESS |
IBUKI A150 Series Air Horn employs a diaphragm driven by compressed-air, and operation is controlled either manually or via a solenoid.
A150 ESS model is compact and light weight body.
IBUKI A150ESS AIR HORN, LLYODS APPROVED C/W:
– MAGNET VALVE, 110VAC / 1PH
– MANUAL PULL VALVE
FOR VESSEL 75M TO LESS THAN 200M
ORIGIN: JAPAN
Heater and snow guard are available for use in cold area
Detail
IBUKI A150 Series air horn employs a diaphragm driven by compressed-air, and operation is controlled either manually or via a solenoid.
A150ESS model is compact and light weight body.
Heater and snow guard are available ofr us in cold area.
IMPA CODE: 370105, 370106, 370107, 370185, 370186, 370187, 370188, 370189, 370190, 370191, 370192, 370193, 370195, 370196, 370197, 370198, 370199
NKK Approved
HK Approved
370191AIR HORN FOR HULL L 75-200MTR
Required installation under the international regulations for preventing collisions at sea. The frequency of the horns shall be between 130 – 350 Hz for a vessel greater than 75 mtrs but less than 200 mtrs in length, and 70 – 200 Hz for a vessel 200 mtrs or more in length.
| Short Description | Class II air horn for vessels 75m to 200m in length IP56 |
|---|---|
| Description | A100ESS series air horn employs a diaphragm driven by compressed air and operation is controlled either manually or solenoid; It compact and light weight body |
| IMPA Code | 370186/370189/370192 |
| Application | For vessels 75m to 200m in length |
| Brand |  |
| Voltage | 100V / 220V AC / 24V DC |
| Watts | NO WATTS |
